Trail camera for hunting

Animal or events observation
Motion-triggered security camera, for home, office and community
All other indoor/outdoor surveillence where invasion evidence needed

• Programmable 5 or 12-Megapixel high-quality resolution.
• Infrared night vision blue LEDs for flash range as far as 65 feet
• In "Cam + Video" mode, camera takes both pictures and video at every trigger event
• Ultra low standby power consumption. Extremely long in-field life (in standby mode, up to 6 months with 8 x AA batteries)
• Unique side Prep Sensor design provides wider sensing angle and enhances camera's response speed
• Perform in the most extreme temperatures from -22°F to 158°F
• Compact size (5 ½ x 3 ½ x 2 ½ inches). Well designed to deploy covertly
• Impressively quick trigger time (1.2 second)
• Under Time Lapse setting, works as Time-lapse camera taking pictures/videos at specified interval
• When Timer setting on, programmable to only work in specified period every day. This feature can be used together with Time Lapse feature to meet your timetable
• Backpack-looking tree grabber makes mounting and aiming a snap
• Serial Number setting enables you to code locations in the photos, helping multi-camera users identify the location when reviewing the photos on home computer
• Built-in 2 ¼" TFT color display to review images and videos
• Date, time can be stamped in the pictures
• Lockable and password protected
• Two MMS image size options: 640 x 480 or 320 x 240
• Camera and MMS function can be conveniently configured by running the enclosed CD on the computer
• Separation of the Camera and the MMS module provides users flexibility: starting with the standard scouting camera, and upgrading to the Cellular model with MMS function.
• Advanced Remote Cellular Technology transmits images to your cell phone and email account constantly at lower battery consumption and shorter transmission time, compared to products of its kind on the market.
• Check cellular signal information on the built-in TFT display in the field
• All MMS pictures, as well as the original ones, saved on SD card
• Internal antenna design makes the camera portable while still emitting strong signal
• Operates globally via GSM/GPRS network. Supports four bands: 850 / 900 / 1800 / 1900MHz.

TECHNICAL SPECIFICATION

Model	Parameters
Image Sensor	12 Mega Pixels Color CMOS
Max. Pixel Size	4000x3000
Lens	F=3.1; FOV=55°; Auto IR-Cut
IR Flash	65 Feet/20 Meters; 30 Feet/10 Meters on
	Low-glow Flash
LCD Screen	48x35mm(2.36"); 480(RGB)*234DOT;
	16.7M Color
Memory	SD Card (8MB ~ 32GB)
Picture Size	5MP/12MP/1.3MP =
	2560X1920/4000X3000/1280X960;
Video Size	1280x720P: 30fps; 640x480: 20fps; 320x240: 20fps
PIR Sensing	65ft/20m(Below 77°F/25°C at the Normal
Distance	Level)
Prep PIR	Left and right light beams form an angle
Sensing Angle	of 100°; Each lens covers 25°
Main PIR Sensing	58°
Angle
Trigger Time	1.1 Second (When using the 2G SD card)
Camera + Video	First take Picture then Video
MMS Status	VGA = 640x480; QVGA = 320x240; SMS;OFF
	Programmable
MMS Numbers	"0" = Unlimited; 0 ~ 99/Day
MMS Phone No.	1 ~ 3 Phone Numbers
MMS E-mail	1 ~ 3 E-mail addresses
Power Supply	4xAA; Expandable to 8xAA
External DC	Plug Size: 4.0x1.7
Power Supply	6 ~ 12V (1 ~ 2A)
Stand-by Current	0.4mA
Stand-by Time	3~6 Months(4xAA~8xAA)
Power	150mA (+350mA when IR LED lights up)
Consumption
Interface	TV out (NTSC); USB; SD Card Slot; 6V
	DC External
Waterproof	IP54
Language	English/Chinese/French/Norwegian/Deutsch/Spanish/Portuguese/Japanese/Russian/Finnish
	/Portuguese/Japanese/Russian/Finnish
Operation	-22~+158°F/-30 ~+70°C
Temperature
Operation	5% ~ 95%
Humidity
Certificate	FCC & CE & ROHS
